Failure of a Prestressed Concrete Steel Strand

Macrography of one wire that was fully cracked, in a longitudial section. The morphology shows multiple corrosion-fatigue cracking.

7

62
of one that was fully cracked, in a longitudial section. The morphology shows multiple - .
M

Material

High Carbon Steel
  • UNS G10700
Ds

Description

After several years in service in an urban atmosphere the rope presented multiple in the region that was exposed to the environment, out of the concrete. The analysis indicated that about 75% of the wires broke by a - mechanism and only 25% by . The lower loading capacity of the wires was generated by the wire thicknesses losses and by the corrosion-, indicating that the material preservation was not suitable.

C

Chemistry (% in weight)

Wire analysis

0.75C; 1.14Si; 0.82Mn; 0.020P; 0.018S; 0.02Cr; 0.04Ni.
