What is in a case
Every case is built the same way — the record an engineer would want if the sample were on their own bench.
Aspect Before Analysis
Low Carbon Steel
The exact alloy and heat treatment tested — never a generic grade.
0.18C; 0.16Si; 0.58Mn; 0.012P
Elemental composition, in percent by weight.
Structure
Where the part was in service when the sample was taken.
Rolled Plate
The manufactured form — plate, pipe, forging, casting.
Plate (load 1 kg) — 1 test
Mechanical test results — tensile, hardness, impact.
Ferritic pearlitic · Strain Hardened · Deformed Structure
What the metal looks like under the microscope.
The low carbon steel plate, 3/8" thickness, was shot with a .308 Winchester projectile (cooper alloy case filled with lead-antimony alloy)…
The engineer’s own account of what happened and why.
