ML00029 - Jan.2017

Titanium Plate for Subsea Application

Alpha and beta phases. Refined Structure.

2

52
and . Refined .
M

Material

Ti6Al4V
  • UNS R56400
  • ASTM B 265 grade 5
Ds

Description

The material was adopted in a structural part.

C

Chemistry (% in weight)

Product Analysis

89.2Ti; 5.93Al; 4.31V; 0.03Zr; 0.06Sn; 0.36Cr.

Associated Images
The plate longitudinal section presents a granular refined structure. Biphasic.
340
VIEW
ML00029 / Jan.2017
Titanium Plate for Subsea Application
M - Ti6Al4VP - Rolled PlateAp - StructureCd - Typical manufacturing
Cm - Micrography by OM, HF + HNO3 + H2O etchDf - Grain refined structure
Alpha and beta phases. Refined Structure.
52
VIEW
ML00029 / Jan.2017
Titanium Plate for Subsea Application
M - Ti6Al4VP - Rolled PlateAp - StructureCd - Typical manufacturing
Cm - Micrography by OM, HF + HNO3 + H2O etchDf - Two phases
Alpha and beta phases. Refined Structure.
46
VIEW
ML00029 / Jan.2017
Titanium Plate for Subsea Application
M - Ti6Al4VP - Rolled PlateAp - StructureCd - Typical manufacturing
Cm - Micrography by OM, HF + HNO3 + H2O etchDf - Two phases
