ML00090 - Sep.2017

Carbon Steel Tubing for Structural Application

Micrographic detail of the slightly banded perlitic structure, in the center of the thickness. ND 3". 7.6 mm thick.

1

530
Micrographic detail of the slightly banded perlitic , . 3". 7.6 mm thick.
M

Material

Low Carbon Steel
  • ASTM A 500 grade A
Ds

Description

The round shape seamless was qualified to be adopted in a structual support.

C

Chemistry (% in weight)

Product Analysis

0.21C; 0.20Si; 0.54Mn; 0.021P; 0.007S; 0.03Cr; 0.03Ni; 0.02Cu.

Associated Images
Micrographic detail of the slightly banded perlitic structure, in the center of the thickness. ND 3". 7.6 mm thick.
530
VIEW
ML00090 / Sep.2017
Carbon Steel Tubing for Structural Application
M - Low Carbon SteelP - TubeAp - StructureCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Ferrite and Pearlite
Micrography of a longitudinal section of the tube, in the center of the thickness. ND 3". 7.6 mm thick.
55
VIEW
ML00090 / Sep.2017
Carbon Steel Tubing for Structural Application
M - Low Carbon SteelP - TubeAp - StructureCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Ferrite and Pearlite
Micrography of a longitudinal section of the tube, in the center of the thickness. ND 3". 7.6 mm thick.
43
VIEW
ML00090 / Sep.2017
Carbon Steel Tubing for Structural Application
M - Low Carbon SteelP - TubeAp - StructureCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Longitudinal Section
