ML00024 - Dec.2017

3/4" CMn Steel Plate for Pressure Vessel

Ferritic perlitic microstructure, banded, in the center of the 3/4" thick C-Mn plate. Refined Structure.

3

29
perlitic , banded, in the center of the 3/4" thick C- . Refined .
M

Material

CMn Steel
  • ASTM A 537 Class 1
Ds

Description

The presented a refined and was qualified for manufacturing.

C

Chemistry (% in weight)

Product Analysis

0.21C; 0.26Si; 1.24Mn; 0.020P; 0.005S; 0.02Cr; 0.20Ni; 0.007Mo; 0.01Cu.

Associated Images
Ferritic perlitic microstructure, banded, in the center of the 3/4" thick C-Mn plate. Refined Structure.
349
VIEW
ML00024 / Dec.2017
3/4" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Grain refined structure
Ferritic perlitic microstructure, banded, in the center of the 3/4" thick C-Mn plate. Refined Structure.
31
VIEW
ML00024 / Dec.2017
3/4" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Banded Pearlite
Ferritic perlitic microstructure, banded, in the center of the 3/4" thick C-Mn plate. Refined Structure.
29
VIEW
ML00024 / Dec.2017
3/4" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Longitudinal Section
