ML00022 - Dec.2017

1/2" CMn Steel Plate for Pressure Vessel

Ferritic perlitic microstructure, banded, in the center of the 1/2" thick C-Mn plate. Refined Structure.

2

32
perlitic , banded, in the center of the 1/2" thick C- . Refined .
M

Material

CMn Steel
  • ASTM A 537 Class 1
Ds

Description

The presented a refined and was qualified for manufacturing.

C

Chemistry (% in weight)

Product Analysis

0.19C; 0.27Si; 1.27Mn; 0.017P; 0.004S; 0.02Cr; 0.21Ni; 0.01Mo; 0.01Cu.

Associated Images
Ferritic perlitic microstructure, banded, in the center of the 1/2" thick C-Mn plate. Refined Structure.
327
VIEW
ML00022 / Dec.2017
1/2" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Grain refined structure
Ferritic perlitic microstructure, banded, in the center of the 1/2" thick C-Mn plate. Refined Structure.
32
VIEW
ML00022 / Dec.2017
1/2" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Banded Pearlite
Ferritic perlitic microstructure, banded, in the center of the 1/2" thick C-Mn plate. Refined Structure.
29
VIEW
ML00022 / Dec.2017
1/2" CMn Steel Plate for Pressure Vessel
M - CMn SteelP - PlateAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Longitudinal Section
