ML00030 - Jan.2017

Forging for High Pressure Application

Longitudinal section of the fitting in the center of the thickness (2"). Refined ferritic structure.

1

370
of the (2"). Refined .
M

Material

Microalloyed Steel
  • ASTM A 694 grade F65
Ds

Description

The was qualified for use as a in high pressure and low temperature .

C

Chemistry (% in weight)

Product Analysis

0.12C; 0.20Si; 1.29Mn; 0.013P; 0.015S; 0.034Nb; 0.042V.

Associated Images
Longitudinal section of the fitting in the center of the thickness (2"). Refined ferritic structure.
370
VIEW
ML00030 / Jan.2017
Forging for High Pressure Application
M - Microalloyed SteelP - Machined PartAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Bainitic Ferrite
Longitudinal section of the fitting in the center of the thickness (2"). Refined ferritic structure.
66
VIEW
ML00030 / Jan.2017
Forging for High Pressure Application
M - Microalloyed SteelP - Machined PartAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Grain refined structure
Longitudinal section of the fitting in the center of the thickness (2"). Refined ferritic structure.
63
VIEW
ML00030 / Jan.2017
Forging for High Pressure Application
M - Microalloyed SteelP - Machined PartAp - Oil and GasCd - Typical manufacturing
Cm - Nital Etched Micrography by OMDf - Grain refined structure
